Bosch ZEMO SU-E FS 12 - Torque

MY22Z0a - 12_1.0_25.07.2022
68
Description
3.5.10 Torque
Model Torque Screw
3.5.10.1 Hub
SHIMANO quick release version
FH-M3050, FH-M4050, FH-MT200-B,
FH-MT400, FH-MT400-B, FH-MT500,
FH-MT500-B, FH-MT510, FH-MT510-B,
FH-RM33, FH-RM35, FH-TX505,
FH-TY505, FH-UR600
HB-M3050, HB-M4050, HB-MT200,
HB-MT400,HB-MT400-B, HB-RM33
HB-TX505
SLX
FH-M7000, FH-M7010, FH-M7010-B
HB-M7000, HB-M7010, HB-M7010-B
DEORE
FH-M618, FH-M618-B, FH-M6000,
FH-M6010, FH-M6010-B,
HB-M618, HB-M618-B, HB-M6000,
HB-M6010, HB-M6010-B
Brake disc attachment screw
40 Nm Adjustable spanner and special tool TL-LR15
(SHIMANO)
SHIMANO E-THRU quick release axle
Retaining ring for brake disc 40 Nm Special tool TL-FC36 (SHIMANO)
SHIMANO, FH-M3050, FH-M4050,
FH-M7000, FH-M6000, FH-RM33,
FH-RM35, FH-UR600
Attachment screw, freewheel body 35 … 50 Nm 10 mm hex bit
SHIMANO, FH-MT200, FH-TX505,
FH-TY505
Attachment screw, freewheel body 147 … 200 Nm 12 mm hex bit
SHIMANO, FH-M7010, FH-M7010-B,
FH-M6010, FH-M6010-B, FH-M618,
FH-M618-B, FH-MT400, FH-MT400-B
FH-MT500, FH-MT500-B, FH-MT510
FH-MT510-B
Lock nut 15 … 20 Nm Hub spanner, 17 mm
SHIMANO, HB-M7000, HB-M6000,
HB-M4050
Lock nut 10 … 15 Nm Hub spanner, 13 mm and 17 mm
SHIMANO, HB-M7010, HB-M7010-B,
HB-M6010, HB-M6010-B, HB-M618,
HB-M618-B, HB-MT400, HB-MT400-B
Lock nut 21 … 26 Nm Hub spanner, 22 mm
SHIMANO hub dynamo
E2 model
20 - 25 Nm Screw wrench
SHIMANO hub dynamo
J2 model
20 Nm Screw wrench
SHIMANO hub dynamo
J2-A model
20 Nm Screw wrench
3.5.10.2 Shifter
SHIMANO DEORE SL-M4100
Attachment screw 3 Nm 4 mm hex bit
SHIMANO DEORE SL-M5100
Attachment screw 3 Nm 4 mm hex bit
SHIMANO DEORE SL-M6100
Attachment screw 3 Nm 4 mm hex bit
SHIMANO DEORE XT SL-M8100
Attachment screw 3 Nm 4 mm hex bit
SHIMANO DEORE XT SL-M8130
Attachment screw 3 Nm 4 mm hex bit
