Description
SHIMANO, SLX SL-M7100
Attachment screw 3 Nm 4 mm hex bit
SHIMANO XTR SL-M9100
Attachment screw
3 Nm 4 mm hex bit
3.5.10.3 Rear derailleur
SHIMANO for MTB/trekking
Attachment screw, standard type
8–10 Nm Hex key, 5 mm
SHIMANO for MTB/trekking
Attachment screw with bracket
3–4 Nm Hex key, 5 mm
SHIMANO for BMX bicycles
Attachment screw
3–4 Nm Adjustable spanner
SHIMANO for MTB/trekking
Attachment screw for inner cable
6–7 Nm Hex key, 4 mm/
Hex key, 5 mm/
Adjustable spanner
SHIMANO for MTB/trekking
Attachment screw for the guide pulley
2.5–5 Nm Hex key, 3 mm
SHIMANO for MTB/trekking
Attachment screw for the tensioning
roller
2.5–5 Nm Hex key, 3 mm
SHIMANO for racing bicycles
Attachment screw, standard type
8–10 Nm Hex key, 5 mm
SHIMANO for racing bicycles
Attachment screw with bracket
3–4 Nm Screw wrench
SHIMANO for racing bicycles
Attachment screw for inner cable
6–7 Nm Hex key, 4 mm/
Hex key, 5 mm
SHIMANO for racing bicycles
Attachment screw for pulley
2.5–5 Nm Hex key, 3 mm
3.5.10.4 Front derailleur
SHIMANO for MTB/trekking
Attachment screw, clip type,
E-type and direct fitting
5–7 Nm Hex key, 5 mm
SHIMANO for MTB/trekking
Inner bearing adapter
35–50 Nm …
SHIMANO for MTB/trekking
Top swing screw, clip type and
e-type
5–7 Nm Hex key, 5 mm/
Screw wrench, 9 mm
SHIMANO for MTB/trekking
Down swing screw, clip type, direct fitting
5–7 Nm Hex key, 5 mm
SHIMANO for racing bicycles
Attachment screw
5–7 Nm Hex key, 5 mm/
Screw wrench, 9 mm
SHIMANO for racing bicycles
Attachment screw, Bowden cable
6–7 Nm Hex key, 5 mm/
3.5.10.5 Freewheel
SHIMANO 35 Nm Multiple freewheel tool TL-FW30
3.5.10.6 Axle
Conventional axle nut 35 … 40 Nm*
SR SUNTOUR screw-on axle 12AH2
Axle
Securing screw
8–10 Nm
5–6 Nm
6 mm hex bit
5 mm hex bit
SR SUNTOUR screw-on axle 15AH2
Axle
Securing screw
8–10 Nm
5–6 Nm
6 mm hex bit
5 mm hex bit
