Bosch ZEMO SU-E FS 12 - Page 71

MY22Z0a - 12_1.0_25.07.2022
70
Description
3.5.10.7 Handlebars
Clamping screw, conventional 5 … 7 Nm*
CONTROL TECH, handlebar clamp
with one or two screws
14 … 16 Nm
SHIMANO, handlebar clamp with one
or two screws
20 … 29 Nm
3.5.10.8 Stem
FSA, carbon quill stem, 9 Nm 15 mm spanner
3.5.10.9 Seat post
by.schulz, G1
M8 seat clamp screw
M5 fixing grub screws
20 … 24 Nm
3 Nm 2.5 mm hex bit
by.schulz, G2
M6 seat clamp screw
M5 fixing grub screws
12 … 14 Nm
3 Nm 2.5 mm hex bit
eightpins NGS2
Seat post axle
Slipper clutch
Valve cover
Postpin axle
Rear clamping screw (saddle)
M5 attachment screw for outer sleeve
8Nm
18 Nm
0.5 Nm
8Nm
8Nm
0.5 Nm
6 mm hex bit
3 mm hex bit
5 mm hex bit
5 mm hex bit
3 mm hex bit
3 mm hex bit
eightpins H01
Seat post axle
Slipper clutch
Valve cover
Postpin axle
Rear clamping screw (saddle)
M5 attachment screw for outer sleeve
8Nm
18 Nm
0.5 Nm
8Nm
8Nm
0.5 Nm
6 mm hex bit
3 mm hex bit
5 mm hex bit
5 mm hex bit
3 mm hex bit
3 mm hex bit
LIMOTEC LimoDP
Clamping screw for seat post
Clamping screw for saddle
6 … 7 Nm
7 … 9 Nm
SR SUNTOUR suspension seat post
Seat clamp screw
M5 fixing grub screws
15 … 18 Nm
3 Nm 2.5 mm hex bit
3.5.10.10 Seat post remote control
eightpins
Attachment screw
Bowden cable fastener
2.5 Nm
5Nm
4 mm hex bit
3 mm hex bit
3.5.10.11 Pedal
Pedal, conventional 33 … 35 Nm Screw wrench, 15 mm
SHIMANO
Attachment screw
35–55 Nm Screw wrench, 15 mm
3.5.10.12 Handbrake
SHIMANO
Attachment screw
6–8 Nm Hex key, 4 mm
Hex key, 5 mm
SHIMANO
Attachment screw, BL-M987/
BL-M9000/BL-M9020
4–6 Nm Hex key, 4 mm
SHIMANO, lever for disc brake
Bleed nipple
4–6 Nm Socket wrench, 7 mm
SHIMANO, lever for disc brake
Bleed screw
0.3–0.5 Nm …
