Description
3.5.10.13 Brake cable
SHIMANO
Connecting screw, handbrake
5–7 Nm
Screw wrench, 8 mm
SHIMANO
Connecting screw, brake calliper, version
for banjo type connection
5–7 Nm
8–10 Nm
Hex key, 3 mm
Hex key, 4 mm
SHIMANO
Connecting screw for brake calliper,
straight version
5–7 Nm Hex key, 3 mm
SHIMANO for racing bicycles
Connecting screw for cable sleeve
5–7 Nm
Screw wrench, 8 mm
3.5.10.14 Brake linings
SHIMANO
Circlip
2–4 Nm Hex key, 3 mm
Slotted-head screwdriver
3.5.10.15 Brake calliper
SHIMANO
Adapter attachment screw and brake
calliper attachment screw, version with IS
brake mount
6–8 Nm …
SHIMANO
Brake calliper attachment screw, post-
mount version
6–8 Nm …
3.5.10.16 Disc brake
SHIMANO for centre lock type
Attachment screw, quick release
40–50 Nm TL-LR15
TL-FC36/TL-LR11
Adjustable spanner
SHIMANO for centre lock type
Attachment screw, nut version
40–50 Nm TL-LR10
Screw wrench
SHIMANO for 5-hole version
Attachment screws
2–4 Nm Star bit [no. 25]
SHIMANO for 6-hole version
Attachment screws
2–4 Nm Star bit [no. 25]
3.5.10.17 V-Brake brake
SHIMANO
Attachment screw for connecting cable
6–8 Nm Hex key, 5 mm
SHIMANO
Brake shoe nut
6–8 Nm Hex key, 5 mm
SHIMANO
Bowden cable attachment screw
6–8 Nm Hex key, 5 mm
3.5.10.18 Dual pivot rim brake
SHIMANO
Attachment screw
8–10 Nm Hex key, 5 mm
SHIMANO, models with nut
Attachment screw
8–10 Nm Screw wrench, 10 mm
SHIMANO
Attachment screw for brake shoe
5–7 Nm Hex key, 4 mm
SHIMANO, left side
Attachment screw for brake cable
6–8 Nm Hex key, 5 mm
SHIMANO, right side
Attachment screw for brake cable
1–1.5 Nm Hex key, 2 mm
