Bosch ZEMO SU-E FS 12 - Page 73

MY22Z0a - 12_1.0_25.07.2022
72
Description
3.5.10.19 Cantilever brake
SHIMANO
Brake caliper attachment screw
5–7 Nm Hex key, 5 mm
SHIMANO
Attachment screw for brake shoe
8–9 Nm Hex key, 5 mm
Screw wrench, 10 mm
SHIMANO
Bowden cable attachment screw
6–8 Nm Hex key, 5 mm
3.5.10.20 Chainring
SHIMANO, for MTB/trekking
Largest chainring/medium-sized
chainring
Smallest chainring
14–16 Nm
16–17 Nm
…
SHIMANO, single version
Attachment screw for crank/chainring
12 … 14 Nm Hex key, 5 mm/star bit [no. 30]
SHIMANO, dual version
Largest chainring
Smallest chainring
12 … 14 Nm
16–17 Nm
Hex key, 5 mm/star bit [no. 30]
Hex key, 5 mm/star bit [no. 30]
SHIMANO, triple design
Largest chainring/medium-sized
chainring
Smallest chainring
12 … 14 Nm
16–17 Nm
Hex key, 5 mm/star bit [no. 30]
Hex key, 5 mm/star bit [no. 30]
SHIMANO, FC-M8000, single version
Attachment screw for crank/chainring
12 … 14 Nm Star bit [no. 30]
SHIMANO, FC-M8000, dual version
Largest chainring
Smallest chainring
12 … 14 Nm
16–17 Nm
Star bit [no. 30]
Star bit [no. 30]
SHIMANO, FC-M8000, triple version
Largest chainring/medium-sized
chainring
Smallest chainring
10 … 12 Nm
16–17 Nm
Star bit [no. 30]
Star bit [no. 30]
3.5.10.21 Crank bearing/crank set
Conventional cartridge crank bearing
35–45 Nm
…
SHIMANO, HOLLOWTECH Ii/two-part
crank set
Linker for adapter and inner sleeve
35–50 Nm TL-FC24/TL-FC25/TL-FC32/TL-FC36
SHIMANO, HOLLOWTECH Ii/two-part
crank set
Cap
0.7–1.5 Nm TL-FC16 / TL-FC18
SHIMANO, HOLLOWTECH Ii/two-part
crank set
Screw for left-hand crank arm
12–14 Nm Hex key, 5 mm
SHIMANO, OCTALINK model
Linker for adapter and main body
50–70 Nm TL-UN74-S/ TL-UN66
SHIMANO, OCTALINK model
Crank set
35–50 Nm Hex key, 8 mm
Hex key, 10 mm
SHIMANO, SQUARE model
Linker for adapter and body
50–70 Nm TL-UN74-S
SHIMANO, SQUARE model
Crank set
35–50 Nm Hex key, 8 mm
