Description
3.4.3 Battery level indicator (battery)
Each battery has its own level indicator:
Figure 46: Position of battery level indicator (1)
The five green LEDs on the battery level indicator
battery show the charge level when the battery is
switched on.
Each LED represents about 20% battery capacity.
All five LEDs will light up when the battery is fully
charged. If the battery level falls below 5%, all the
LEDs on the operating status and battery level
indicator will go out.
