Operation
9 Take off the cover cap to remove or reposition
the preload spacer.
On a new vehicle, the 5-mm preload position of
the preload spacer is positioned as
standard (1).
Figure 147: Screwing and unscrewing the preload
adjustment ring
Remove the preload spacer to reduce the
preload and increase the sag (2).
Move the preload spacer to the 10-mm preload
position to increase preload and reduce the
sag (3).
Figure 148: Screwing and unscrewing the preload
adjustment ring
10 Check the sag.
