Troubleshooting, fault clearance and repair
9.1.13.3 Suspension too soft on inclines
The fork deflects at a low point in the terrain. The
deflection is quickly used up, body weight shifts
forward and the pedelec loses some momentum.
Figure 242: Excessively soft suspension in the suspension fork on hilly terrain
Solution
Figure 243: Changing compression adjuster to a harder
setting
Turn compression adjuster in a clockwise
direction towards LOCK.
The damping and compression hardness are
increased and the deflection stroke speed.
Efficiency on hilly and flat terrain is improved.
