Troubleshooting, fault clearance and repair
9.1.15.3 Suspension too soft on inclines
The rear frame damper deflects deeply through
the deflection range The deflection is quickly used
up, body weight shifts downwards and the pedelec
loses some momentum.
Figure 258: Excessively soft suspension in the rear frame damper on hilly terrain
Solution
Figure 259: SR SUNTOUR compression adjuster (1) on the
rear frame damper
Turn compression adjuster clockwise.
The damping and compression hardness is
increased, and the deflection stroke speed is
reduced. Efficiency on hilly and flat terrain is
improved.
