Troubleshooting, fault clearance and repair
9.1.16 RockShox rear frame damper
9.1.16.1 Rebound too fast
The rear frame damper rebounds too quickly,
producing a "pogo stick" effect or causing the bike
to bounce after the wheel hits a bump and lands
on the ground again. This impairs traction and
control due to the uncontrolled speed at which the
damper rebounds after deflecting (blue line).
Saddle and handlebars are deflected upwards
when the wheel bounces back from the ground.
The rider's body weight may be shifted upwards
and forwards if the damper fully rebounds too
quickly (green line).
Figure 262: Rear frame damper rebounding too quickly
Solution
Figure 263: Position and shape of the rebound adjuster (red) depends on the model
Turn rebound adjuster in a clockwise direction.
Rebound damping is increased. The rebound
speed is reduced and traction and control is
increased.
