Troubleshooting, fault clearance and repair
9.1.16.3 Suspension too soft on inclines
The rear frame damper deflects deeply through
the deflection range. Deflection is quickly used up,
to the pedelec rider's weight shifts forward and the
pedelec loses some momentum.
Figure 266: Excessively soft suspension in the rear frame damper on hilly terrain
Solution
Figure 267: Position and shape of the compression adjuster (blue) depends on the model
Turn compression adjuster clockwise.
The damping and compression hardness is
increased, and the deflection stroke speed is
reduced.
