Brady BradyPrinter i7100 - Winding Up The Media Strip In Rewind Mode

18
User Manual
7 Loading Material
7.1.4 Winding up the Media Strip in Rewind Mode
6 75
2
4
1
3
8
Figure13 Guidingthemediastripinrewindmode
Inrewindmode,thelabelsarewoundupinternallyafterprintingforlateruse.
NOTE: a PEEL conguration printer, or standard printer upgraded with PEEL is required.
1. Installrewindguidingplate(7.4onpage22).
2. Liftthepinchroller(4)offtherewindassistroller.
3. Guidelabelstriparoundtherewindguidingplate(2)totheinternalrewinder(7).
4. Holdrewinder(7)rmlyandturnknob(6)clockwiseuntilitstops.
5. Pushlabelstripunderabracket(5)oftherewinderandturnknob(6)counterclockwiseuntilitstops.
Therewinderisfullyspread,thusgrippingthelabelstriprmly.
6. Turnrewinder(7)counterclockwisetotightenthelabelstrip.
7. Turnlever(1)clockwisetolocktheprinthead.
Thelabelrollisloadedforuseinrewindmode.
