7.6 Setting the Feed Path of the Transfer Ribbon
Transferribbonwrinklingcanleadtoprintimageerrors.Thetransferribbondeection(3)canbeadjustedsoasto
preventwrinkles.
i
Note!
A maladjustment of the head locking system may also cause ribbon wrinkling ( 7.3 on page 22).
1
2
3
Figure21 Settingthefeedpathofthetransferribbon
i
Note!
The adjustment is best carried out during printing.
 Readcurrentsettingonthescale(1)andrecordifnecessary.
 Turnscrew(2)withAllenkeyandobservethebehavioroftheribbon.
Inthe+direction,theinneredgeoftheribbonistightened,andtheouteredgeistightenedinthe-direction.
