6.2 Navigation in the Menu
Startlevel Selectionlevel Parameter/functionlevel
Figure8 Menulevels
 Toopenthemenuselect
onthestartscreen.
 Selectathemeintheselectionlevel.
Severalthemeshavesubstructuresagainwithselectionlevels.
Toreturnfromthecurrentleveltotheupperoneselect
.Toleavethemenuselect .
 Continuetheselectionuntiltheparameter/functionlevelisreached.
 Startafunction.Thewillcarryoutthefunctionpossiblyafterapreparingdialogue.
-or-Selectaparametertoset.Thesetuppossibilitiesaredependingfromtheparametertype.
Logicalparameters Selectionparameters Numericalparameters Date/time
Figure9 Samplesforparametersetting
Scrollbarforroughvaluesetting
Decreasingthevaluestep-by-step
Increasingthevaluestep-by-step
Returnwithoutsavingthesetting
Returnwithsavingthesetting
Parameterisdisabled,touchingenablestheparameter
Parameterisenabled,touchingdisablestheparameter
Figure10 Buttonsforparametersetting
