User Manual
8 Printing Operation
!
Attention!
Printhead damage caused by improper handling!
 Do not touch the underside of the printhead with the ngers or sharp objects.
 Ensure that the labels are clean.
 Ensure that the label surfaces are smooth. Rough labels act like emery paper and reduce the service life
of the printhead.
 Print with the lowest possible printhead temperature.
Theprinterisreadyforoperationwhenallconnectionshavebeenmadeandlabelsand,ifapplicable,thetransfer
ribbonhavebeenloaded.
8.1 Synchronization of the Paper Feed
Afterthelabelstockhasbeeninserted,forpeel-offorcuttingmodeasynchronizationofthepaperfeedisrequired.
Thatwaytherstlabel,whichisdetectedbythelabelsensor,willbetransportedtotheprintpositionandalllabelsin
frontwillbefedoutoftheprinter.Sothesynchronizationavoids,thatblanklabelsarepeeled-offtogetherwiththerst
printedlabelorthattherstcutlabelwouldbetoolong.Botheffectscancauseuselessrstlabels.
 Select
tostartthesynchronization.
 Removetheblanklabelspeeled-offorcutduringthesynchronization.
i
Note!
Synchronization is not necessary if the printhead was not opened between different print jobs, even if the
printer was switched off.
8.2 Tear-off Mode
Intear-offmode,labelsorcontinuousmediaareprinted.Afterprinting,thelabelstripcanbeseparatedbyhand.The
labelprintermustbeequippedwithatear-offplateforthis7.4onpage22.
8.3 Peel-off Mode
InPeel-offmode,thelabelsareautomaticallypeeledoffthelinerafterprintingandpresentedforremoval.Theliner
iswoundupbytheinternalrewinder.ThismodeisavailableonlyonthePEELprinterversions.Theprintermustbe
equippedwithadispenseplate.7.4onpage22
!
Attention!
Peel-off mode must be activated in the software.
This is done with the "P command" in the direct programming,  Programming Manual.
• Inthemostsimplecasethepeel-offmodecanbecontrolledwithoutoptionaldevicebythetouchscreendisplay:
 Startaprintjobinpeel-offmode.
 Starteverypeel-offcyclebypressing
onthetouchscreendisplay.
• WhenusingtheoptionalPS1000presentsensor,thelabelinthepeelpositionwillbedetectedbyanoptical
sensor.Afterthelabelhasbeenremovedthenextlabelwillbeprintedandfedtothepeelpositionseparate
documentation.
8.4 Internal Rewinding
Thelabelsarewoundupinternallyafterprintingwiththecarriermediumforlateruse.Thismodeisavailableonlyon
thePEELprinterversions.
Thelabelprintermustbeequippedwitharewindguidingplateforthis7.4onpage22
