11 Media
11.1 Media Dimensions
  Labels      ContinuousMaterial
Feed direction
Figure24 Mediadimensions
Dimension
Code
Designation Dimension (mm)
B Labelwidth 4 -110
H Labelheight
in peel-off mode
4 - 2000
12 - 200
- Tear-offlength > 30
- Cutlength
 withcutter
 withperforationcutter
> 5
> 5
- Perforationlength > 2
A Labeldistance > 2
C Widthofliner 9 - 114
GE Widthofendlessmaterial 4 - 114
GS Widthofshrinktubes 4 - 85
DL Leftmargin ≥0
DR Rightmargin ≥0
E Labelthickness 0,03-0,60
F Linerthickness 0,03-0,13
QE Thicknessofendlessmaterial 0,05-0,50
QS Thicknessofshrinktubes ≤1,1
V Labelfeed > 6
• Smalllabelsizes,thinmaterialsorstronggluecanleadtolimitations.
Criticalapplicationsneedtobetestedandcleared.
• Notethebendingstiffness!Materialmustbeexibletofollowtheradiusoftheprintroller!
Table6 Mediadimensions
