11.3 Reex Mark Dimensions
Feed direction
virtual label front edge
reex mark
Labelswithreexmarks ContinuousMaterialwithreexmarks
Figure26 Reexmarkdimensions
Dimension
Code
Designation Dimension (mm)
A Labeldistance > 2
AZ Distancebetweenprintzones > 2
L Widthofreexmark > 5
M Heightofreexmark 3 - 10
XL Distancemark-materialedge 5 - 60
XM Distancemark-middleofpapertrack -55 - ±0
Z Distancevirtuallabelfrontedge-actuallabelfrontedge
 Adjustsoftwaresettings
0uptoA/
recomm.:0
• Reexmarksmustbeonthebacksideofthematerial(liner).
• Labelsensorforreexmarksonthetopsideonrequest.
• Specicationisvalidforblackmarks.
• Recognitionofcoloredmarksmayfail.Preliminarytestsareneeded.
Table8 Reexmarkdimensions
