User Manual
5 Installation
5.2 Unpacking and Setting-up the Printer
 Liftthelabelprinteroutofthebox.
 Checklabelprinterfordamagewhichmayhaveoccurredduringtransport.
 Setupprinteronalevelsurface.
 Removefoamtransportationsafeguardsneartheprinthead.
 Checkdeliveryforcompleteness.
Contentsofdelivery:
• Labelprinter
• Powercable
• USBcable
• Operator'sManual
• CDwithWindowsdriveranddocumentation
i
Note!
Please keep the original packaging in case the printer must be returned.
!
Attention!
The device and printing materials will be damaged by moisture and wetness.
 Set up label printers only in dry locations protected from liquid.
5.3 Connecting the Device
ThestandardavailableinterfacesandconnectorsareshowninFigure3.
5.3.1 Connecting to the Power Supply
Theprinterisequippedwithawideareapowerunit.Thedevicecanbeoperatedwithasupplyvoltageof
230V~/50Hzor115V~/60Hzwithoutadjustment.
1. Checkthatthedeviceisswitchedoff.
2. Plugthepowercableintothepowerconnectionsocket(24).
3. Plugthepowercableintoagroundedsocket.
5.3.2 Connecting to a Computer or Computer Network
!
Attention!
Inadequate or no grounding can cause malfunctions during operations.
Ensure that all computers and cables connected to the label printer are grounded.
 Connectthelabelprintertoacomputerornetworkbyasuitablecable.
FordetailsofthecongurationoftheindividualinterfacesCongurationManual.
5.4 Switching on the Device
Whenallconnectionshavebeenmade:
 Switchtheprinteronatthepowerswitch(23).
Theprinterperformsasystemtest,andthenshowsthesystemstatusReadyinthedisplay(10).
