User Manual
10.3 Problem Solution
Problem Cause Remedy
Transferribboncreases Transferribbondeectionnotadjusted Adjustthetransferribbondeection.
7.5onpage24
Headlockingsystemnotadjusted Adjusttheheadlockingsystem.
7.3onpage22
Transferribbontoowide Useatransferribbonslightlywiderthan
thewidthoflabel.
Printimagehassmearsor
voids
Printheadisdirty Cleantheprinthead
9.4onpage26
Temperaturetoohigh Decreasetemperatureviasoftware.
Unsuitablecombinationoflabelsand
transferribbon
Usedifferenttypeofribbon.
Printerdoesnotstopafter
transferribbonrunsout
Thermalprintingischoseninthesoftware Changetothermaltransferprinting.
Printerprintsasequence
ofcharactersinsteadofthe
labelformat
PrinterisinASCIIdumpmode CanceltheASCIIdumpmode.
Printertransportslabel
media,buttransferribbon
doesnotmove
Transferribbonincorrectlyinserted. Checkand,ifnecessary,correctthe
transferribbonwebandtheorientation
ofthelabelside.
Unsuitablecombinationoflabelsand
transferribbon
Usedifferenttypeofribbon.
Printeronlyprintseach
secondlabel
Settingofthesizeinthesoftwareistoo
large.
Changethesizeinthesoftware.
Verticalwhitelinesinthe
printimage
Printheadisdirty Cleantheprinthead
9.4onpage26
Printheadisdefective(failureofheat
elements)
Changetheprinthead.
ServiceManual.
Horizontalwhitelinesinthe
printimage
Printerisusedwiththebackfeed > smart in
thecutorpeel-offmode
Setthebackfeed > alwaysinthesetup.
CongurationManual.
Printimageisirregular,one
sideislighter
Printheadisdirty Cleantheprinthead
9.4onpage26
Headlockingsystemnotadjusted Adjusttheheadlockingsystem.
7.3onpage22
Table5 Problemsolution
10 Fault Correction
