User Manual
11.4 Cut out Mark (notch) Dimensions
Feed direction
Labelswithcut-outmarks(notches) ContinuousMaterialwithcut-out
marks(notches)
formarginalcut-outmarks
minimumlinerthickness0,06mm
Figure27 Cut-outmarkdimensions
Dimension
Code
Designation Dimension (mm)
A Labeldistance > 2
AZ Distancebetweenprintzones > 2
N Widthofcut-outmark
formarginalcut-out
> 5
> 8
P Heightofcut-outmark 2 - 10
XL Distancemark-materialedge 5 - 60
XM Distancemark-middleofpapertrack -53 - ±0
Y Sensorrecognizedvirtuallabelfrontedgewithgapsensorrecognition Rearedgecut-out
Z Distancerecognizedfrontedge-actuallabelfrontedge
 Adjustsoftwaresettings
0uptoA-P
Table9 Cut-outmarkdimensions
Marginalcut-out Longholecut-out Rectangularcut-out Circular cut-out
Cut-out
betweenthelabels
Notrecommended!
Figure28 Samplesforcut-outmarks
11 Media
