Brady BradyPrinter i7100 - Installation; Printer Overview

10
User Manual
5 Installation
5.1 Printer Overview
3
5
6
7
8
4
1
9
10
2
11
1 Cover
2 Marginstop(center-justied)
3 Marginstop(outer)
4 Roll retainer
5 Ribbonsupplyhub
6 Ribbontake-uphub
7 Internalrewinder
8 Print unit
9 Cover(notonPEELcongurations)
10 Touchscreendisplay
11 LED"Poweron"
Figure1 Overview
13
14
18
19
16
12
21
22
15
17
20
12 Ribbondeection
13 Printheadretainerwithprinthead
14 Labelsensor
15 Allenkey
16 Printheadlockinglever
17 Print roller
18 Guideadjustingknob
19 Guide
20 Dispenseplate
21 Rewindassistroller
(onlyPEELcongurations)
22 Lockingsystem
(onlyPEELcongurations)
Figure2 Print unit
