11.2 Printer Dimensions
Gap sensor
& Reective sensor
Printhead
Peel-off edge
Tear-off edge
Cut edge
Feed direction
Figure25 Devicedimensions
Dimension
Code
Designation Dimension (mm)
IP Distanceprinthead-peel-offedge 13,5
IT Distanceprinthead-tear-offedge 13,5
IC Distanceprinthead-cutedge
withcutterCU400(Bradypart#149069)
withperforationcutterPCU400(Bradypart#149078)
20,5
21,2
J Distance1stheatingpoint-materialedge 2,0
K Printwidth 105,6
SX Distancegap/reectivesensor-middleofpapertrack
i.e.permissibledistanceofreexorcut-outmarksfromthe
middleofthematerial
-55 - 0
SY Distancegap/reectivesensor-
printhead
45,0
Table7 Devicedimensions
11 Media
