Brady M611 - Printer Components

M611 Label Printer User Manual 4
Setup
Printer Components
Printer Components
1
Supply door (label supply well)
6
Supply door open tabs
2
AC adapter port
7
Bulk or external label feed path
3
USB port (computer connection)
8
Magnet attachment screw hole
4
USB host port (phone charging and
firmware upgrades)
9
Ribbon
5
Power button
10
Lock lever
1
2 3 4
5
6
7
8
9
10
