M611 Label Printer User Manual 17
Setup
Loading Supplies
Loading Bulk Labels
To load bulk labels:
1. Remove the label spool
and the label feed ramp
from the box.
2. On the bulk label box,
push tabs A and C in,
then pull the perforated
flap down and tear off.
3. Attach the label feed
ramp to the bottom of the
perforation, with the
ramp arms on the
outside of the box.
4. Attach the ramp hooks to
the outside of the bulk
label feed path on the
printer.
5. Insert the label spool into
the printer so that the
smart cell aligns with the
reader in the label well.
Adjust the label guide as
needed.
