Servicing the Unit
4 - 2 Infusomat® Space 6.0
EN
Internal tube routing areas
The slide guide and the internal tube guides can be cleaned with
d
isinfectants containing 1-propanol or didecyl dimenthyl ammo-
nium chloride.
The slide guide can be prised out with a pointed object (ballpoint
p
en) through a notch in the housing front panel on the right lower
side (Fig.: 4 - 2). The cover can then be cleaned by immersing it,
the pump slide can be cleaned with a soft cloth.
When you reinsert the slide guide, make sure it is not damaged
a
nd audibly snaps into place.
Cleaning of the connector
Corroded or soiled connector conta
cts can result in connection
problems and fault messages output during operation. After it has
been identified by a visual or function check, clean the offending
connector as follows.
Cleaning agents and materials:
*
- Contact cleaner: Kontakt WL, order no. 20.710.6.13.12.01 or
DeoxIT® D5 Spray, part no. D5S-6
†
- Contact spray: Kontakt 60 plus, order no. 20.739.6.09.12.01
or DeoxIT® D1
00 Spray, part no. D100S-2
†
- Cleaning brush: Kontakt Chemie, ref. no. 30206 (3 each) or
Co
nnector Cleaning Brush, part no. AB-25 (25 each)
†
- Swabs: Chemtronics Chamois Tips CC
50 (50 each) or DeoxIT®
Precision Foam Swabs, part no. SWPX-25 (25 each)
†
Fig.: 4 - 3 Example: connector on SpaceStation
Connector corroded Connector cleaned
*
Not all products are available in all regions.
†
Caig Laboratories, Inc. (www.caig.com)
