Disassembly / Assembly
3
Infusomat® Space 6.0 3 - 39EN
3. Slide the connector seal P2 (Fig.: 3 - 41 / Item 1) onto the
connector enclosure using a scalpel.
In order to avoid bubbling press the connector seal P2 (Fig.: 3 - 42
/ Item 1) on completely.
Fig.: 3 - 41
Legend of fig. 3 - 41:
Item Designation
1 Connector seal P2
1
Fig.: 3 - 42
Legend of fig. 3 - 42:
Item Designation
1 Connector seal P2
1
