142 Brocade FastIron X Series Chassis Hardware Installation Guide
53-1001723-02
Installing or replacing a power supply
6
1. Use a Phillips-head or flathead screwdriver to loosen the latch screw in the front upper right
corner of the power supply. Once the screw is loosened, the latch will spring gently forward and
down.
2. Insert the new power supply into the empty power supply slot as shown in Figure 53.
Do not attempt to install the power supply without first loosening the retaining screw on the front
of the power supply. Attempting to install the power supply with a closed latch will result in
mechanical damage to the power supply and power supply slot.
Make sure the power supply is properly inserted in the slot. Never insert the power supply upside
down.
3. When the power supply is almost fully seated in the chassis, press firmly on the power supply
latch until it locks into place. Refer to Figure 53.
Use caution when closing the latch. Your fingers could get caught or pinched between the latch
and the front of the power supply.
4. When the power supply is fully seated, tighten the retaining screw as shown in Figure 53.
5. Connect power to the chassis. Refer to “Connecting AC power to the chassis” on page 145.
