Brocade FastIron X Series Chassis Hardware Installation Guide 175
53-1001723-02
Appendix
A
Layer 3 Upgrade Procedures
Overview
This appendix describes how to upgrade your device to run the full Layer 3 software code.
If you have any questions about performing this upgrade, please contact your place of purchase or
Brocade at 800-752-8061 inside the United States or +1-408-333-6061 outside the United States.
You also can send e-mail to IPsupport@brocade.com.
The procedures in this manual are for qualified service personnel.
Upgrade kit contents
Before beginning the upgrade, please verify the package contents. If any items are missing from
the kit, contact your place of purchase. The upgrade kit contains the following:
• Electrostatic Discharge (ESD) protection kit
• Upgrade instructions (this document)
• Dual Inline Package (DIP) key for upgrade (the chip that has eight pins). You should have one of
the part numbers listed in Table 40.
TABLE 40 FastIron switches in which a Layer 3 upgrade DIP key can be installed
Management Module Upgrade DIP Key Part Number DIP Socket Placement on Main Board
SuperX IPv4 Management Modules
SX-FI12GM-4
SX-FI12GM2-4
SX-FIL3U U53
SuperX IPv6 Management Modules
SX-FI12GM-6
SX-FI12GM2-6
SX-FIL3U-6-IPV4
SX-FIL3U-6-IPV6
U53
FSX 800 and FSX 1600 IPv4 Management Modules
SX-FIZMR
SX-FI2XGMR4
SX-FI8GMR4
SX-FIL3U U63
FSX 800 and FSX 1600 IPv6 Management Modules
SX-FI2XGMR6
SX-FI8GMR6
SX-FIL3U-6-IPV4
SX-FIL3U-6-IPV6
U63
