170 Brocade FastIron X Series Chassis Hardware Installation Guide
53-1001723-02
Power supply specifications
7
Power supply specifications
This section contains the following information for the power supplies that ship with the FastIron X
Series chassis devices:
• “Physical dimensions and weight”
• “Environmental considerations”
• “Electrical specifications”
• “Input connector and plug”
• “Regulatory compliance”
• “Safety warnings”
For an overview of the power supplies, refer to “Power supplies” on page 31.
Physical dimensions and weight
Table 33 lists the physical dimensions and weight of the power supplies.
Environmental considerations
TABLE 33 Physical dimensions and weight of power supplies
Dimensions Weight
Replacement power supplies SX-ACPWR-SYS and SX-ACPWR-POE (manufacturing part numbers
32014-xxx and 32016-xxx
1
, respectively)
1. Manufacturing part numbers are inscribed on the power supply (top) label.
4.19 cm (H) x 10.17 cm (W) x 38.10 cm (D)
1.65 in. (H) x 4.00 in. (W) x 15 in. (D)
2.7 kg (6 lbs)
All other power supplies
4.13 cm (H) x 10.17 cm (W) x 36.19 cm (D)
1.63 in. (H) x 4.00 in. (W) x 14.25 in. (D)
2.7 kg (6 lbs)
TABLE 34 Environmental considerations for power supplies
Property SX-ACPWR-SYS and
SX-ACPWR-POE
SX-DCPWR-SYS and
SX-DCPWR-POE
SX-ACPWR2500-POE
Operating Environment
Operating temperature -0
to 40 C, 23 to 122 F-0 to 40 C, 23 to
122
F
-0
to 40 C, 23 to
122
F
Relative humidity 0 – 95%, non-condensing 0 – 95%,
non-condensing
0 – 95%,
non-condensing
