Brocade Communications Systems FastIron X Series Hardware Installation Guide

Brocade FastIron X Series Chassis Hardware Installation Guide 159
53-1001723-02
Chapter
7
Hardware Specifications
Overview
This chapter contains chassis and power supply specifications for the Brocade FastIron X Series
chassis devices.
Chassis specifications
The following sections present the hardware specifications for the FastIron X Series chassis
devices.
Physical dimensions
Table 25 lists the physical dimensions and weight for the FastIron X Series chassis devices.
Environmental considerations
For optimal performance, operate or store your Brocade device in compliance with the following
environmental conditions.
TABLE 25 Physical dimensions and weight of the FSX chassis
Device Height Width Depth Weight (fully
loaded)
FSX 26.6 cm
(10.46 in.)
48.3 cm (19 in.) including the
mounting brackets
44.3 cm (17.45 in.) behind the
mounting brackets
44.4 cm
(17.5 in.)
97 lbs
FSX 800 26.6 cm
(10.46 in.)
48.3 cm (19 in.) including the
mounting brackets
44.3 cm (17.45 in.) behind the
mounting brackets
49.5 cm
(19.50 in.)
97+ lbs
FSX 1600 62.1 cm
(24.46 in.)
44.1 cm (17.38 in.) including the
mounting brackets
43.7 cm (17.2 in.) behind the
mounting brackets
57.3 cm
(22.55 in.)
195.70 lbs
FSX 1600-ANR 62.1 cm
(24.46 in.)
44.1 cm (17.38 in.) including the
mounting brackets
43.7 cm (17.2 in.) behind the
mounting brackets
67.4 cm
(26.55 in.)
204 lbs
