Brocade Communications Systems FastIron X Series Hardware Installation Guide

42 Brocade FastIron X Series Chassis Hardware Installation Guide
53-1001723-02
Unpacking a system
2
Unpacking a system
The FastIron X Series ships with several items. Please review the list below and verify the contents:
NOTE
If any items are missing, please contact the place of purchase.
• FSX or FSX 800, or FSX 1600 chassis with the following installed:
• one or two 12-volt power supplies
• fan tray assembly or assemblies
• slot panels installed in all unoccupied slots
• The FSX 800 and FSX 1600 also come with two switch fabric modules already installed
• Rack Mount Kit (FSX 1600 models only)
• Management module or modules (packaged separately)
• Optional interface modules (packaged separately)
• Warranty card
• A 115V AC power cable for each AC power supply you purchase from Brocade
DANGER
If the installation requires a different power cord than the one supplied with the device, make
sure you use a power cord displaying the mark of the safety agency that defines the regulations
for power cords in your country. The mark is your assurance that the power cord can be used
safely with the device.
6 The chassis ships with a slot panel installed in all
module slots that do not currently have a module
installed. If you plan to install a module in a slot, you
must remove the slot panel.
CAUTION: If you do not install a module in a slot, you
must keep the slot panel in place. If you run the
chassis with an uncovered slot, the system will
overheat.
“Removing the slot panels” on page 50
7 Install the management module and interface
modules in the chassis
“Installing the management and interface
modules” on page 51
8 Attach a management station to the management
module’s serial (Console) port or a 10/100/1000
Ethernet port.
“Attaching a management station” on
page 56
9 Power on the AC power supplies. “Powering on the system” on page 58
10 After the chassis is powered on, observe the LEDs or
display the status of the modules using the CLI to
determine that the chassis is operating properly.
“Verifying proper operation” on page 63
TABLE 15 FSX hardware installation tasks (Continued)
Task Number Task Where to Find More Information
