Brocade FastIron X Series Chassis Hardware Installation Guide 165
53-1001723-02
Chassis specifications
7
Power source interruptions
Table 31 shows how the FastIron chassis protects against power surges and power drops.
Pinouts and signalling
This section lists the pinouts for the DB-9 connector and RJ-45 port jacks.
48-port GbE copper interface module 90 N/A 4 8
FSX and FSX 800 fans 2066N/A
FSX 1600 fans 80 N/A N/A 2
Maximum Power Consumption in a Fully Loaded, Functional Chassis
FSX 990
FSX 800 1200
FSX 1600 2050
1. For a list of part numbers for the Management and Interface modules,
refer to the following:
“FSX management modules on page 14
“FSX 800 and FSX 1600 management modules” on page 18
“Interface modules” on page 23
TABLE 31 Chassis power surge and drop protection
Property Protection Mechanism
Power surge MOV and Spark Gap protection
Power drop An AC loss of >15ms will cause the power supply to shut down due to input
under-voltage
TABLE 30 Maximum power consumption (Continued)
Hardware Component
1
Maximum Power
Consumption
(Watts)
Maximum Number of Components per Chassis
FSX
FSX 800 FSX 1600
