Hardware features
1
Network interfaces
Table 13 lists the network interfaces supported on the FastIron X Series chassis devices. For
network interface and cabling specifications, refer to Table 32 on page 168.
The output of the show media command displays the type of media installed in the ports.
Ports on th e FastIron X Series chassis devices are grouped into regions. For a few features, such as port monitoring and unknown unicast configurations, you will need to know the region to which a port belongs. However, for most features, a port’s region does not affect configuration or operation of the feature. If a port’s region does affect configuration or operation of a feature, it is noted and described in the ap propriate feature section of this guide.
• FSX Management Module:
• Ports 1 – 12
• FSX 800 and FSX 1600 Management Module with 2-port 10-GbE
• Port 1
• Port 2
• FSX 800 and FSX 1600 Management Module with 8-port GbE copper and fiber ports
• Ports 1 – 8
• 24-port Gigabit Ethernet Copper Interface Module
TABLE 13 Network interfaces
Interface Show Media Description
1000Base-BX-D M-GBXD
1000Base-BX-U M-GBXU
1000Base-CWDM Cxxxx
1
1. xxxx denotes the wavelength. For example, C1550.
1000Base-LHA M-LHA
1000Base-LHB M-LHB
1000Base-LX M-LX
1000Base-SX M-SX
1000Base-SX2 M-XR or M-SX2
1000Base-T M-C
100Base-BX M-FBXD or M-FBXU
100Base-FX M-FX, M-FXB1, or M-FXB2
100Base-FX-IR M-FX-IR
100Base-FX-LR M-FX-LR
100Base-FX-SR M-FX-SR
100Base-TX
2
2. Supported on copper ports only.
M-TX
10GBase-1310-MMF 1310-MMF
10GBase-CX4 XG-CX4
10GBase-ER XG-ER
10GBase-LR XG-LR
10GBase-SR XG-SR
10GBase-ZR XG-ZR
10GBase-ZRD XG-ZRD
