164 Brocade FastIron X Series Chassis Hardware Installation Guide
53-1001723-02
Chassis specifications
7
Maximum power consumption
Table 30 lists the maximum power consumption for the modules and other components in the
Brocade chassis.
TABLE 29 Regulatory compliance
Certifications
Emissions
• Canada Interference Causing Equipment Regulations
• EN 55022 / CISPR-22 Class A / VCCI Class A
• FCC Class A
Electromagnetic
• EN 61000-3-2 Power Line Harmonics
• EN 61000-4-2 ESD
• EN 61000-4-3 Radiated Immunity
• EN 61000-4-4 EFT
• EN 61000-4-5 Surge
• EN 61000-4-6 Low Frequency Common Immunity
• EN 61000-4-11 Voltage Dips and Sags Generic: EN 50082-1
• ESD: IEC 61000-4-2; 4 kV CD, 8 kV AD
• Radiated: IEC 61000-4-3; 3 V/m
• EFT/Burst: IEC 61000-4-4; 1.0 kV (power line), 0.5 kV (signal line)
• Conducted: IEC 61000-406; 3 V
Safety Agency
• CAN/CSA-C22.2 No. 60950-1-03 / UL 60950-1 – 1st Edition, Safety of Information Technology Equipment
• EN 60825-1 Safety of Laser Products – Part 1: Equipment Classification, Requirements and User’s Guide
• EN 60825-2 Safety of Laser Products – Part 2: Safety of Optical Fibre Communications Systems
• EN 60950-1 / IEC 60950-1 – Safety of Information Technology Equipment
TABLE 30 Maximum power consumption
Hardware Component
1
Maximum Power
Consumption
(Watts)
Maximum Number of Components per Chassis
FSX
FSX 800 FSX 1600
FSX Management Module 150 1 N/A N/A
FSX 800 and FSX 1600 Management
Module with 2 10-GbE ports
135 N/A 2 2
FSX 800 and FSX 1600 Management
Module with no ports
65 N/A 2 2
FSX 800 and FSX 1600 Management
Module with 8 ports
100 N/A 2 2
Switch Fabric module in the FSX 800
chassis
45 N/A 2 N/A
Switch Fabric module in the FSX 1600
chassis
90 N/A N/A 2
2-port 10-GbE interface module, including
fiber optics
908816
24-port GbE copper interface module 90 8 8 16
24-port GbE fiber interface module,
including fiber optics
908816
