Brocade FastIron X Series Chassis Hardware Installation Guide 157
53-1001723-02
Replacing the air filter in the FastIron SX-1600
6
4. Insert the new fan assembly into the fan slot and push the enclosure in until the face plate is
flush with the chassis. Pushing the enclosure in seats the fan connector with the chassis
connector.
5. Secure the fan to the chassis by tightening the two captive screws.
6. Access the CLI, and enter the show chassis command to verify that both fans are operating
normally.
Replacing the air filter in the FastIron SX-1600
It is recommended that Brocade switches and routers be installed in environments that have
minimal dust and airborne contaminants. If Brocade switches and routers are placed in operation
in environments where dust or other airborne contaminants may be prevalent, air filters should be
inspected annually and replaced if needed. Maintaining clean air filters ensures optimal airflow
through the device.
To replace the air filter in the FastIron SX-1600, perform the following tasks.
1. Loosen the captive fasteners in the front of the filter retainer.
2. Pull the filter retainer away from the chassis as shown in Figure 58.
