36 Brocade FastIron X Series Chassis Hardware Installation Guide
53-1001723-02
Hardware features
1
TABLE 14 Power supply LEDs
LED Desired State Meaning Abnormal State Meaning or Action
AC OK (AC
supply only)
ON – Green (steady) The power supply is
receiving AC power from
an AC power source
OFF The power supply is not
receiving power from an
AC power source. You can
do the following:
• Make sure that the
power supply cord is
connected securely
to the wall outlet
and the power
supply.
• Make sure that the
wall outlet is rated
for 115/120V and
20A. If it is not,
obtain a cable that
is compatibly rated
for the outlet.
• Make sure that the
wall outlet has
power.
DC IN (DC
supply only)
Green (steady) The power supply is
receiving DC power from a
DC power source
OFF The power supply is not
receiving power from a
DC power source. You
can do the following:
• Make sure that the
power supply cables
are connected
securely to the
power source and
the power supply.
• Make sure that the
DC power source is
48VDC @ 37.0 A.
• Make sure that the
power source has
power.
DC OUT ON – Green (steady) The power supply is
supplying DC output power
to the chassis
OFF The power supply is not
supplying DC output
power to the chassis.
If this occurs and the AC
OK (AC power supply) or
DC IN (DC power supply)
LED is Green, then there
is a problem with the
power supply and it must
be replaced.
ALM OFF No alarms present and the
power supply is in normal
operating condition.
Amber There is an alarm
present and the power
supply is malfunctioning.
Verify the AC or DC input
and DC output voltages.
