Brocade FastIron X Series Chassis Hardware Installation Guide 45
53-1001723-02
Installation precautions
2
running while a power supply is being installed or removed, but the power supply itself should not
be connected to a power source. Otherwise, you could be injured or the power supply or other
parts of the device could be damaged.
If the installation requires a different power cord than the one supplied with the device, make
sure you use a power cord displaying the mark of the safety agency that defines the regulations
for power cords in your country. The mark is your assurance that the power cord can be used
safely with the device.
Make sure to choose the appropriate circuit device depending on the number of AC power
supplies installed in the chassis. The minimum current draw for the system is one AC power
supply.
Make sure that the power source circuits are properly grounded, then use the power cord
supplied with the device to connect it to the power source.
Disconnect the power cord from all power sources to completely remove power from the device.
Do not install the device in an environment where the operating ambient temperature might
exceed 40
o
C (104
o
F).
All devices with DC power supplies are intended for installation in restricted access areas only. A
restricted access area is where access can be gained only by service personnel through the use
of a special tool, lock and key, or other means of security, and is controlled by the authority
responsible for the location.
For a DC system, use a grounding wire of at least 6 American Wire Gauge (AWG). The 6 AWG wire
should be attached to an agency-approved crimp connector crimped with the proper tool. The
crimp connector should allow for securement to both ground screws on the enclosure. For the
