BRONKHORST BRIGHT - PID Controller Settings

6 | SETTINGS MENU
9.17.048
Page 21
To enter the master slave settings screen, select the
master slave option from the controller settings screen
and press to enter.
Depending of the selected mode the following parameters
can be selected:
fb ana slave
analog slave
fb slave
Master node
o
o
slave factor
o
o
6.9 PID controller settings
You can tune the controller settings by changing the PID
parameters. To edit these parameters use the button
to select the ‘pid controller’ option and press again.
You can find more information about these
controller settings in the manual: 9.17.023 ,
This manual is available at the download
section of our website:
http://www.bronkhorst.com
In the pid-controller settings screen you can select one of
the PID parameters using the and buttons. Press
to enter the edit mode.
SET
SET
SET
