12 ADF unit - Main PCB ASSY
Harness colors are subject to change for some reason.
Upper document chute ASSY
Lower document chute ASSY
Document Scanner unit
Second side CIS flat cable
Second side document scanning
position sensor PCB harness (BL)
ADF motor
harness (RD)
Main PCB ASSY
ADF FFC holder
Second side CIS
flat cable
FFC holder ASSY
ADF sensor harness (WH)
ADF FG harness (GN)
