Brother DCP-L5600DN Service Manual

2-67
Confidential
 Error code 9001
When printing from the MP tray, the size of paper set in the MP tray does not match the size
specified by the driver.
Error code 9002
When printing from the paper tray 1, the size of paper set in the paper tray 1 does not match
the size specified by the driver.
Error code 9003
When printing from the paper tray 2, the size of paper set in the paper tray 2 does not match
the size specified by the driver.
Error code 9004
When printing from the paper tray 3, the size of paper set in the paper tray 3 does not match
the size specified by the driver.
Error code 9005
When printing from the paper tray 4, the size of paper set in the paper tray 4 does not match
the size specified by the driver.
Error code 9006
When printing from the paper tray 5, the size of paper set in the paper tray 5 does not match
the size specified by the driver.
<User Check>
• Change the driver setting to be matched with the size of the paper set in the paper tray.
Step Cause Remedy
1
Registration rear actuator
caught in some sections of the
machine
Reattach the registration rear actuator.
2
Registration rear sensor failure Replace the registration front/rear sensor PCB
ASSY.
3 Main PCB failure Replace the main PCB ASSY.

Brother DCP-L5600DN Specifications

General

Type	all in one
Color	black/gray, multi
Touch Screen	yes
Display Size	3.7 inches
Tray Capacity	50
Output Tray Capacity	150 sheets
Automatic Document Feeder Capacity	70 sheets
Paper Size	ansi a, legal, executive, a4, a5, a6, folio
Paper Handling	letter, legal, executive, a4, a5, a6, envelopes, custom sizes (3.0-8.5" (w), 5.0-14" (l))
Paper Weight	60 grams per square meter
Printing Method	monochromatic
Color Print Speed	0 pages per minute
Mono Print Speed	42 pages per minute
First Page Print Time	7 seconds
Print Resolution Mono	up to 1200 x 1200
Two-Sided Printing	yes
Maximum Number of Pages Per Month	up to 50, 000
Reduction and Enlargement	no
Photo Printing	no
Scanner Type	flatbed
Scan Resolution	up to 1200 x 1200
Duplex Scan	yes
Max Copies	99
Copier Resolution Mono	up to 1200 x 600
Fax Function	no
Cartridges	brother tn820, brother tn850
Number Of Cartridges	1
Internal Memory	yes
Memory Card	no
Network	wired
Connectivity	usb 2.0, ethernet
Mobile Devices Connection	no

Weight and Dimensions

Depth	16.8 inches
Height	16.8 inches
Width	19.5 inches
Net Weight	37.7 pounds
