Brother DCP-L5600DN Service Manual

2-12
Confidential
3. ERROR INDICATIONS
This machine includes a self-diagnosis function. If the machine does not work normally it
judges that an error has occurred, and indicates the corresponding error message on the
LCD, which in turn helps the service personnel to quickly find out the problem.
3.1 Error Codes
Errors in shaded column do not usually occur during normal use. The possible causes are
noise around the installation site, fluctuation of the power supply voltage, and failures in the
software.
Error
codes
Description
Refer
to:
Error
codes
Description
Refer
to:
0101 ― 0504
After the heat unit was heated
normally, the center thermistor of the
fuser unit detected a temperature
lower than the specified value.
2-40
0102
Communication error between the
engine ASIC and motor driver or faulty
motor driver.
2-38 0505
The center thermistor of the fuser unit
detected a temperature rise greater
than the specified value within the
specified time.
2-40
0201
Cannot detect the synchronized signal
of the paper feed motor.
The speed of the paper feed motor
does not stabilize within the specified
time.
2-38 0506
The center thermistor of the fuser unit
detected a temperature fall greater
than the specified value within the
specified time.
2-40
0202 ― 0508
The side thermistor of the fuser unit
did not detect a temperature rise
when the heater was ON.
2-40
0203 Eject motor failure was detected. 2-38 050A
The hardware detected a temperature
error through the center thermistor or
the side thermistor of the fuser unit.
2-41
0300
Cannot detect the lock signal of the
polygon motor for the laser unit
(second time).
2-39 050B
When the center thermistor of the
fuser unit was lower than the idle
temperature, the side thermistor
detected a temperature higher than
the specified temperature.
2-41
0305
Cannot detect the lock signal of the
polygon motor for the laser unit (first
time).
2-39 050C
When the center thermistor of the
fuser unit was higher than the idle
temperature, the side thermistor
detected a temperature lower than the
specified temperature.
2-41
0401
Cannot detect the synchronized signal
of the polygon motor for the laser unit
(second time).
2-39
050D ―
0402 ― 050F ―
0405
Cannot detect the synchronized signal
of the polygon motor for the laser unit
(first time).
2-39 0800
An error occurred in the internal
temperature sensor.
2-41
0501
The center thermistor of the fuser unit
has not reached the specified
temperature within the specified time.
2-40 0900
Detected irregular power supply for
more than 100 times.
2-42
0502
The center thermistor of the fuser unit
has not reached the specified
temperature within the specified time
after it was heated normally to the
certain level.
2-40
0A01 ―
0503
The center thermistor of the fuser unit
detected a temperature higher than
the specified value.
2-40 0A02 Detected a main fan failure. 2-42

Brother DCP-L5600DN Specifications

General

Type	all in one
Color	black/gray, multi
Touch Screen	yes
Display Size	3.7 inches
Tray Capacity	50
Output Tray Capacity	150 sheets
Automatic Document Feeder Capacity	70 sheets
Paper Size	ansi a, legal, executive, a4, a5, a6, folio
Paper Handling	letter, legal, executive, a4, a5, a6, envelopes, custom sizes (3.0-8.5" (w), 5.0-14" (l))
Paper Weight	60 grams per square meter
Printing Method	monochromatic
Color Print Speed	0 pages per minute
Mono Print Speed	42 pages per minute
First Page Print Time	7 seconds
Print Resolution Mono	up to 1200 x 1200
Two-Sided Printing	yes
Maximum Number of Pages Per Month	up to 50, 000
Reduction and Enlargement	no
Photo Printing	no
Scanner Type	flatbed
Scan Resolution	up to 1200 x 1200
Duplex Scan	yes
Max Copies	99
Copier Resolution Mono	up to 1200 x 600
Fax Function	no
Cartridges	brother tn820, brother tn850
Number Of Cartridges	1
Internal Memory	yes
Memory Card	no
Network	wired
Connectivity	usb 2.0, ethernet
Mobile Devices Connection	no

Weight and Dimensions

Depth	16.8 inches
Height	16.8 inches
Width	19.5 inches
Net Weight	37.7 pounds
