Brother DCP-L5600DN Service Manual

4-1
Confidential
CHAPTER 4 ADJUSTING AND UPDATING
SETTINGS AS REQUIRED
AFTER PARTS
REPLACEMENT
1. IF YOU REPLACE THE MAIN PCB ASSY
 What to do after replacement
• Installing Firmware (Sub Firmware and Main Firmware)
• Adjusting Touch Panel (Function Code: 61)
• Initializing the EEPROM of the Main PCB ASSY (Function Code: 01)
• Configure for Country/Region and Model (Function Code: 74)
• Activating Memory Writing
• Setting Serial Number and Entering Adjusted Value of Laser Unit
• Acquiring White Level Data (Function Code: 55)
• Adjusting Left-end and Upper-end Print Position (Function Code: 45) (TT only)
• Resetting to Factory Shipping State
 What you need to prepare
(1) One USB cable
(2) Create a temporary folder on the C drive of the computer (Windows
®
XP or later).
(3) Service setting tool (BrUsbsn.zip)
Copy this file into the temporary folder created on the C drive. Extract the copied file.
(4) Download utility (FILEDG32.EXE)
Copy this file into the temporary folder created on the C drive.
(5) Maintenance driver (MaintenanceDriver.zip)
When the maintenance driver is not installed on the computer, copy this file into the
temporary folder created on the C drive, and extract the copied file. Refer to “APPENDIX
3 INSTALLING THE MAINTENANCE PRINTER DRIVER” for the installation procedure.
(6) Firmware
(7) USB flash memory
(8) Touch pen
(9) Memory access tool (MemoryAccessTool.exe)
(10) Shipping tool (ShippingTool.exe)
Sub firmware
(PCL/PS-compliant model only)
djf file
(ex. D001G9_A.djf)
Main firmware
