Brother DCP-L5600DN Service Manual

2-34
Confidential
3.3 Communication Errors
How to print the communication error list (Communication List) can be found in “2.1 Print
Communication Error List” in Chapter 5.
Code 1 Code 2 Cause Refer to:
10 07 No document set when calling. 2-123
10 08 Wrong fax number called. 2-123
11 01 No dial tone detected before dialing. 2-123
11 02 Busy tone detected before dialing. 2-123
11 03 2nd dial tone not detected. 2-123
11 05 No loop current detected. 2-123
11 06 Busy tone detected after dialing or receiving a call. 2-123
11 07 No response from the receiver in sending. 2-123
11 08
No response from the remote station in sending Session
Initiation Protocol (SIP).
2-123
11 10 No tone detected after dialing. 2-123
11 11
No acknowledgement returned after Fax2 net command
was sent.
2-123
13 12 Error signal received after Fax2 net command was sent. 2-123
16 09 No Cipher registration 2-123
17 01
Called using a dial number that cannot be used for the
NGN line (33 digits or longer or non numeric characters).
2-123
17 07 No response from the caller in receiving. 2-123
1C 01
Detected that access to the NGN line was not authorized.
(T38: 403 Forbidden)
2-123
1C 02
No file or folder (directory) found as a result of search via
the NGN line. (T38: 404 Not Found)
2-123
1C 03
Remote station does not support the NGN line. (T38: 488
Not Acceptable Here)
2-123
1C 04
SIP (Session Initiation Protocol) connection not possible.
(T38)
USW NGN fax setting is OFF or calling attempted before
acquisition of SIP information.
2-123
1C 05
Internal error detected in the communication network.
(T38)
2-123
1C 06 SIP Server timeout (T38) 2-123
1C 08
An error other than
1C01,1C02,1C03,1C04,1C06,1D01,1D02 or 1D04 was
detected.
2-123
1D 01 Detected that the NGN line was busy. (T38: 486 Busy) 2-123
1D 02
Detected that the NGN line was temporarily unavailable.
(T38: 480 Temporarily Unavailable)
2-123
1D 04
Network cable not connected (Link Down detected) or not
connected to the Network. (T38)
2-123

Brother DCP-L5600DN Specifications

General

Type	all in one
Color	black/gray, multi
Touch Screen	yes
Display Size	3.7 inches
Tray Capacity	50
Output Tray Capacity	150 sheets
Automatic Document Feeder Capacity	70 sheets
Paper Size	ansi a, legal, executive, a4, a5, a6, folio
Paper Handling	letter, legal, executive, a4, a5, a6, envelopes, custom sizes (3.0-8.5" (w), 5.0-14" (l))
Paper Weight	60 grams per square meter
Printing Method	monochromatic
Color Print Speed	0 pages per minute
Mono Print Speed	42 pages per minute
First Page Print Time	7 seconds
Print Resolution Mono	up to 1200 x 1200
Two-Sided Printing	yes
Maximum Number of Pages Per Month	up to 50, 000
Reduction and Enlargement	no
Photo Printing	no
Scanner Type	flatbed
Scan Resolution	up to 1200 x 1200
Duplex Scan	yes
Max Copies	99
Copier Resolution Mono	up to 1200 x 600
Fax Function	no
Cartridges	brother tn820, brother tn850
Number Of Cartridges	1
Internal Memory	yes
Memory Card	no
Network	wired
Connectivity	usb 2.0, ethernet
Mobile Devices Connection	no

Weight and Dimensions

Depth	16.8 inches
Height	16.8 inches
Width	19.5 inches
Net Weight	37.7 pounds
