Brother DCP-L5600DN Service Manual

2-116
Confidential
 Paper jam in the ADF
 Paper jam in the paper eject section of the ADF
4.11.4 Document becomes wrinkled
<User Check>
• Check that the paper used for the document is not thinner than 64 g/m
2
.
• Check that the paper used for the document is not longer than 900 mm (400 mm when
duplex scanning).
• Check that the document guide is adjusted to suit the document size.
Step Cause Remedy
1 Foreign object inside the ADF Remove foreign objects inside the ADF
2
Document scanning position
actuator coming off
Reattach the document scanning position
actuator.
3 Document pinch roller 2 coming off Reattach the document pinch roller 2.
4
Connection failure of document
scanning position sensor harness
Check the connection of the document
scanning position sensor harness, and
reconnect it if necessary.
5
Second side document hold coming
off
Reattach the second side document hold.
6 First side document hold coming off Reattach the first side document hold.
7
Fed at an angle and jammed due to
abrasion of document separate
roller
Replace the document separate roller
ASSY.
8
Document scanning position
sensor failure
Replace the ADF unit.
9 Main PCB failure Replace the main PCB ASSY.
Step Cause Remedy
1
Foreign object in the ADF
document eject path
Remove foreign objects in the ADF
document eject path.
2 Document pinch roller coming off Reattach the document pinch roller.
3 Abrasion of document eject roller Replace the ADF unit.
4 Main PCB failure Replace the main PCB ASSY.
<User Check>
• Check that the document guide is adjusted to suit the document size.
• Check that the document is not curled.
Step Cause Remedy
1
Abrasion of document separate
roller
Replace the document separate roller
ASSY.
2 Abrasion of document feed roller Replace the ADF unit.

Brother DCP-L5600DN Specifications

General

Type	all in one
Color	black/gray, multi
Touch Screen	yes
Display Size	3.7 inches
Tray Capacity	50
Output Tray Capacity	150 sheets
Automatic Document Feeder Capacity	70 sheets
Paper Size	ansi a, legal, executive, a4, a5, a6, folio
Paper Handling	letter, legal, executive, a4, a5, a6, envelopes, custom sizes (3.0-8.5" (w), 5.0-14" (l))
Paper Weight	60 grams per square meter
Printing Method	monochromatic
Color Print Speed	0 pages per minute
Mono Print Speed	42 pages per minute
First Page Print Time	7 seconds
Print Resolution Mono	up to 1200 x 1200
Two-Sided Printing	yes
Maximum Number of Pages Per Month	up to 50, 000
Reduction and Enlargement	no
Photo Printing	no
Scanner Type	flatbed
Scan Resolution	up to 1200 x 1200
Duplex Scan	yes
Max Copies	99
Copier Resolution Mono	up to 1200 x 600
Fax Function	no
Cartridges	brother tn820, brother tn850
Number Of Cartridges	1
Internal Memory	yes
Memory Card	no
Network	wired
Connectivity	usb 2.0, ethernet
Mobile Devices Connection	no

Weight and Dimensions

Depth	16.8 inches
Height	16.8 inches
Width	19.5 inches
Net Weight	37.7 pounds
