Brother DCP-L5600DN Service Manual

2-22
Confidential
3.2 Error Messages
Error message
Description
Error
codes
Refer
to:
First line Second line
Cartridge Error Put the Toner
Cartridge back in.
The new toner sensor could not
detect the new toner cartridge
correctly.
4F01 2-46
Cooling Down Wait for a while. The side thermistor of the fuser
unit or internal temperature sensor
detected a temperature higher
than the specified value.
6801 2-49
Cover is Open Close the ADF cover. The ADF cover sensor detected
that the ADF cover was open.
A400 2-74
Close the Back Cover
of the Machine.
The eject sensor detected that the
fuser cover was open.
6004 2-47
Close the Front Cover. The front cover sensor detected
that the front cover was open.
6001 2-47
Document Jam Clear the scanner jam,
then press Stop.
The document scanning position
sensor detected that the document
length was 90 cm or more during the
one-side scanning.
A200 2-73
The document scanning position
sensor has not detected the
document passing even after the
document has been fed for the
specified time.
A300 2-73
Drum ! Slide the Green tab on
Drum Unit.
Detected discharge that may be
attributable to dirty corona wire on
the drum unit.
6A00 2-50
Firmware Update You must update the
firmware.
Firmware version of the main PCB
is older than that of the TT and LT.
9400 2-71
Ignore Data Press Stop. Detected undecodable data during
printing. Received undecodable
PS data.
--- 4.14.1
Jam 2-sided Pull out the 2-sided
Tray at the back of the
machine and remove
the jammed paper.
The registration front sensor does
not detect paper pass within the
specified time after the first side was
printed in duplex printing mode.
7800 2-62
Jam Inside Open the Front Cover,
pull out the Drum Unit
completely and
remove the jammed
paper.
The eject sensor does not detect
paper pass after the registration rear
sensor detected the paper pass.
7000 2-51
Jam MP Tray Remove the jammed
paper from MP Tray
and press [Retry].
When feeding from the MP tray,
the registration rear sensor does
not detect paper pass within the
specified time after the registration
front sensor detected paper pass.
7200 2-52

Brother DCP-L5600DN Specifications

General

Type	all in one
Color	black/gray, multi
Touch Screen	yes
Display Size	3.7 inches
Tray Capacity	50
Output Tray Capacity	150 sheets
Automatic Document Feeder Capacity	70 sheets
Paper Size	ansi a, legal, executive, a4, a5, a6, folio
Paper Handling	letter, legal, executive, a4, a5, a6, envelopes, custom sizes (3.0-8.5" (w), 5.0-14" (l))
Paper Weight	60 grams per square meter
Printing Method	monochromatic
Color Print Speed	0 pages per minute
Mono Print Speed	42 pages per minute
First Page Print Time	7 seconds
Print Resolution Mono	up to 1200 x 1200
Two-Sided Printing	yes
Maximum Number of Pages Per Month	up to 50, 000
Reduction and Enlargement	no
Photo Printing	no
Scanner Type	flatbed
Scan Resolution	up to 1200 x 1200
Duplex Scan	yes
Max Copies	99
Copier Resolution Mono	up to 1200 x 600
Fax Function	no
Cartridges	brother tn820, brother tn850
Number Of Cartridges	1
Internal Memory	yes
Memory Card	no
Network	wired
Connectivity	usb 2.0, ethernet
Mobile Devices Connection	no

Weight and Dimensions

Depth	16.8 inches
Height	16.8 inches
Width	19.5 inches
Net Weight	37.7 pounds
