Brother DCP-L5600DN Service Manual

2-73
Confidential
 Error code A000
Image processing was not completed correctly because the number of pixels required for
image processing is insufficient in the scanned second side data.
 Error code A200
The document scanning position sensor detected that the document length was 90 cm or
more during the one-side scanning.
 Error code A300
The document scanning position sensor has not detected the document passing even after
the document has been fed for the specified time.
Step Cause Remedy
1
Incorrect correction data for
second side CIS unit
Execute "Set CIS scan area (function code:
55)".
2 Second side CIS unit failure Replace the second side CIS unit.
3 Main PCB failure Replace the main PCB ASSY.
<User Check>
• Set the specified size paper.
• Remove the jammed document.
Step Cause Remedy
1
Document scanning position
actuator caught in some
sections of the machine
Reattach the document scanning position
actuator.
2
Document scanning position
sensor failure
Replace the ADF unit.
3 Main PCB failure Replace the main PCB ASSY.
<User Check>
• Set A4 or Letter size paper.
• Remove the jammed document.
Step Cause Remedy
1
Document scanning position
actuator caught in some
sections of the machine
Reattach the document scanning position
actuator.
2
Connection failure of the
document scanning position
sensor harness
Reconnect the document scanning position
sensor harness.
3
Document scanning position
sensor failure
Replace the ADF unit.
4 Main PCB failure Replace the main PCB ASSY.

Brother DCP-L5600DN Specifications

General

Type	all in one
Color	black/gray, multi
Touch Screen	yes
Display Size	3.7 inches
Tray Capacity	50
Output Tray Capacity	150 sheets
Automatic Document Feeder Capacity	70 sheets
Paper Size	ansi a, legal, executive, a4, a5, a6, folio
Paper Handling	letter, legal, executive, a4, a5, a6, envelopes, custom sizes (3.0-8.5" (w), 5.0-14" (l))
Paper Weight	60 grams per square meter
Printing Method	monochromatic
Color Print Speed	0 pages per minute
Mono Print Speed	42 pages per minute
First Page Print Time	7 seconds
Print Resolution Mono	up to 1200 x 1200
Two-Sided Printing	yes
Maximum Number of Pages Per Month	up to 50, 000
Reduction and Enlargement	no
Photo Printing	no
Scanner Type	flatbed
Scan Resolution	up to 1200 x 1200
Duplex Scan	yes
Max Copies	99
Copier Resolution Mono	up to 1200 x 600
Fax Function	no
Cartridges	brother tn820, brother tn850
Number Of Cartridges	1
Internal Memory	yes
Memory Card	no
Network	wired
Connectivity	usb 2.0, ethernet
Mobile Devices Connection	no

Weight and Dimensions

Depth	16.8 inches
Height	16.8 inches
Width	19.5 inches
Net Weight	37.7 pounds
