Brother DCP-L5600DN Service Manual

3-4
Confidential
4. SCREW TORQUE LIST
Location of screw Screw type Q’ty
Tightening torque
N·m (kgf·cm)
Fuser unit line cover R Taptite bind B M4x12 1 0.80.1 (81)
Fuser unit line cover L Taptite pan B M4x14 1 0.80.1 (81)
Fuser unit Taptite pan B M4x14 1 0.80.1 (81)
Side cover L Taptite bind B M4x12 2 0.80.1 (81)
Side cover R Taptite bind B M4x12 2 0.80.1 (81)
Main shield plate Screw cup M3x8 (Black) 3 0.450.05 (4.50.5)
ADF FG harness
Modem FG harness L
FB FG harness
Panel FG harness Taptite cup S M3x8 SR 1 0.60.1 (61)
ADF/document scanner unit Taptite bind B M4x12 6 0.80.1 (81)
ADF unit (Hinge L ASSY) Taptite bind B M4x12
(Black)
10.80.1 (81)
Hinge L ASSY Taptite bind B M4x12 3 0.80.1 (81)
Hinge R support Taptite cup B M3x10 1 0.50.1 (51)
Hinge arm R Taptite cup B M3x10 3 0.50.1 (51)
ADF front cover Taptite cup B M3x10 2 0.50.1 (51)
ADF separation holder ASSY Taptite cup B M3x10 1 0.50.1 (51)
Upper document chute Taptite cup B M3x10 6 0.50.1 (51)
Panel unit Taptite cup B M3x10 4 0.50.1 (51)
LCD presser Taptite cup B M3x10 3 0.50.1 (51)
Shield plate cover Taptite cup B M3x10 4 0.50.1 (51)
USB host P
CB ASSY Taptite bind B M4x12 2 0.80.1 (81)
Scanner top cover Taptite bind B M4x12 8 0.80.1 (81)
Modem FG harness R
(Frame R side)
Taptite cup S M3x6 SR 1 0.60.1 (61)
Joint cover ASSY Taptite bind B M4x12 6 0.80.1 (81)
Modem FG harness L
(Modem side)
Screw pan (S/P washer)
M3.5x6
10.60.1 (61)
Modem FG harness R
(Modem side)
Screw pan (S/P washer)
M3.5x6
10.60.1 (61)
Modem shield plate Taptite bind B M4x12 2 0.80.1 (81)
Modem shield cover Screw pan (S/P washer)
M3.5x6
10.60.1 (61)
Modem PCB ASSY Taptite cup S M3x6 SR 2 0.50.1 (51)
Veil cover lower Screw cup M3x8 (Black) 1 0.450.05 (4.50.5)
Main PCB ASSY Screw cup M3x8 (Black) 4 0.450.05 (4.50.5)
Top bar
(T1: Models with 520-sheet)
Taptite bind B M4x12
2
0.80.1 (81)
Laser unit Taptite cup S M3x8 SR 4 0.80.05 (80.5)

Brother DCP-L5600DN Specifications

General

Type	all in one
Color	black/gray, multi
Touch Screen	yes
Display Size	3.7 inches
Tray Capacity	50
Output Tray Capacity	150 sheets
Automatic Document Feeder Capacity	70 sheets
Paper Size	ansi a, legal, executive, a4, a5, a6, folio
Paper Handling	letter, legal, executive, a4, a5, a6, envelopes, custom sizes (3.0-8.5" (w), 5.0-14" (l))
Paper Weight	60 grams per square meter
Printing Method	monochromatic
Color Print Speed	0 pages per minute
Mono Print Speed	42 pages per minute
First Page Print Time	7 seconds
Print Resolution Mono	up to 1200 x 1200
Two-Sided Printing	yes
Maximum Number of Pages Per Month	up to 50, 000
Reduction and Enlargement	no
Photo Printing	no
Scanner Type	flatbed
Scan Resolution	up to 1200 x 1200
Duplex Scan	yes
Max Copies	99
Copier Resolution Mono	up to 1200 x 600
Fax Function	no
Cartridges	brother tn820, brother tn850
Number Of Cartridges	1
Internal Memory	yes
Memory Card	no
Network	wired
Connectivity	usb 2.0, ethernet
Mobile Devices Connection	no

Weight and Dimensions

Depth	16.8 inches
Height	16.8 inches
Width	19.5 inches
Net Weight	37.7 pounds
