Brother DCP-L5600DN Service Manual

2-38
Confidential
4. TROUBLESHOOTING
4.1 Error Cause and Remedy
 Error code 0102
Communication error between the engine ASIC and motor driver or faulty motor driver.
 Error code 0201
Cannot detect the synchronized signal of the paper feed motor. The speed of the paper feed
motor does not stabilize within the specified time.
 Error code 0203
Eject motor failure was detected.
Step Cause Remedy
1
Connection failure of the paper
feed motor harness
Reconnect the paper feed motor harness.
2 Paper feed motor failure Replace the paper feed motor.
3 Main PCB failure Replace the main PCB ASSY.
Step Cause Remedy
1
Connection failure of the paper
feed motor harness
Reconnect the paper feed motor harness.
2 Damaged fuser gear Replace the fuser gear.
3 Paper feed motor failure Replace the paper feed motor.
4 Damaged fuser unit Replace the fuser unit.
5
Low-voltage power supply PCB
failure
Replace the low-voltage power supply PCB
ASSY.
6
Damaged part in drive sub
ASSY
Replace the main frame L ASSY.
7 Main PCB failure Replace the main PCB ASSY.
Step Cause Remedy
1
Connection failure of the eject
motor harness
Reconnect the eject motor harness.
2 Eject motor failure Replace the eject motor.
3
Low-voltage power supply PCB
failure
Replace the low-voltage power supply PCB
ASSY.
4 Damaged part in eject gears Replace the main frame L ASSY.
5 Main PCB failure Replace the main PCB ASSY.

Brother DCP-L5600DN Specifications

General

Type	all in one
Color	black/gray, multi
Touch Screen	yes
Display Size	3.7 inches
Tray Capacity	50
Output Tray Capacity	150 sheets
Automatic Document Feeder Capacity	70 sheets
Paper Size	ansi a, legal, executive, a4, a5, a6, folio
Paper Handling	letter, legal, executive, a4, a5, a6, envelopes, custom sizes (3.0-8.5" (w), 5.0-14" (l))
Paper Weight	60 grams per square meter
Printing Method	monochromatic
Color Print Speed	0 pages per minute
Mono Print Speed	42 pages per minute
First Page Print Time	7 seconds
Print Resolution Mono	up to 1200 x 1200
Two-Sided Printing	yes
Maximum Number of Pages Per Month	up to 50, 000
Reduction and Enlargement	no
Photo Printing	no
Scanner Type	flatbed
Scan Resolution	up to 1200 x 1200
Duplex Scan	yes
Max Copies	99
Copier Resolution Mono	up to 1200 x 600
Fax Function	no
Cartridges	brother tn820, brother tn850
Number Of Cartridges	1
Internal Memory	yes
Memory Card	no
Network	wired
Connectivity	usb 2.0, ethernet
Mobile Devices Connection	no

Weight and Dimensions

Depth	16.8 inches
Height	16.8 inches
Width	19.5 inches
Net Weight	37.7 pounds
