Brother DCP-L5600DN Service Manual

2-83
Confidential
4.2.2 No paper is fed from LT
<User Check>
• Check that the paper is set in the paper tray correctly.
• Check that there is not too much paper set in the paper tray.
• Flip over the paper in the paper tray or rotate the paper 180°.
• Check that the thickness of the paper is 60 to 120 g/m
2
(paper tray 2 to 4).
• Check that the MP tray, T1 or TT is not set as the paper tray.
• Flip through the paper and reset it in the paper tray.
• Clean the paper pick up roller.
• Install the latest main firmware.
Step Cause Remedy
1
Dirt on a paper dust cleaning
roller of the paper tray
Clean the appropriate paper dust cleaning
roller. (Refer to Fig. 2-10.)
2
Attachment failure of a roller
holder ASSY
Reattach the appropriate roller holder ASSY
correctly.
3
Connection failure of the paper
feed motor harness
Reconnect the paper feed motor harness.
4
Connection failure of an LT
paper feed sensor harness
Reconnect the appropriate LT paper feed
sensor harness.
5
Connection failure of an LT
control PCB flat cable
Reconnect the appropriate LT control PCB flat
cable.
6
Connection failure of an LT
release clutch harness
Reconnect the appropriate LT release clutch
harness.
7
Connection failure of an LT
pickup clutch harness
Reconnect the appropriate LT pickup clutch
harness.
8
An LT paper empty actuator
coming off
Reattach the appropriate LT paper empty
actuator.
9
Abrasion of a paper pick up
roller
Replace the appropriate PF kit.
10 An LT release clutch failure Replace the appropriate LT release clutch.
11 An LT pickup clutch failure Replace the appropriate LT pickup clutch.
12
An LT paper empty sensor
failure
Replace the appropriate LT paper empty
sensor PCB ASSY.
13 Damaged a plate gear Replace the appropriate plate gear.
14 Damaged fuser gear Replace the fuser gear.
15 Damaged an LT/TT connector Replace the appropriate LT/TT connector.
16 Paper feed motor failure Replace the paper feed motor.
17 An LT control PCB failure Replace the appropriate LT control PCB ASSY.
18 Panel PCB failure Replace the panel PCB ASSY.
19
Damaged LT drive gear system
of the machine
Replace the main frame L ASSY.
20 Damaged fuser unit Replace the fuser unit.
21 Main PCB failure Replace the main PCB ASSY.

Brother DCP-L5600DN Specifications

General

Type	all in one
Color	black/gray, multi
Touch Screen	yes
Display Size	3.7 inches
Tray Capacity	50
Output Tray Capacity	150 sheets
Automatic Document Feeder Capacity	70 sheets
Paper Size	ansi a, legal, executive, a4, a5, a6, folio
Paper Handling	letter, legal, executive, a4, a5, a6, envelopes, custom sizes (3.0-8.5" (w), 5.0-14" (l))
Paper Weight	60 grams per square meter
Printing Method	monochromatic
Color Print Speed	0 pages per minute
Mono Print Speed	42 pages per minute
First Page Print Time	7 seconds
Print Resolution Mono	up to 1200 x 1200
Two-Sided Printing	yes
Maximum Number of Pages Per Month	up to 50, 000
Reduction and Enlargement	no
Photo Printing	no
Scanner Type	flatbed
Scan Resolution	up to 1200 x 1200
Duplex Scan	yes
Max Copies	99
Copier Resolution Mono	up to 1200 x 600
Fax Function	no
Cartridges	brother tn820, brother tn850
Number Of Cartridges	1
Internal Memory	yes
Memory Card	no
Network	wired
Connectivity	usb 2.0, ethernet
Mobile Devices Connection	no

Weight and Dimensions

Depth	16.8 inches
Height	16.8 inches
Width	19.5 inches
Net Weight	37.7 pounds
