Brother DCP-L5600DN Service Manual

App. 2-1
Confidential
APPENDIX 2 DELETING USER SETTING
INFORMATION
The user setting information for the machine is stored in the main PCB. You can return this to
the default settings by following the procedure below.
<Operating Procedure>
(1) Press the [Settings] key while the machine is in the ready state.
(2) Press the [All Settings] key on the LCD.
(3) Press the [Initial Setup] key on the LCD.
(4) Press the [Reset] key on the LCD.
(5) Press the [Factory Reset] key on the LCD.
(6) "Factory Reset? It may take time until reset finishes. Yes No" appears on the LCD. Press
the [Yes] key.
(7) "Machine will reboot after resetting. Press [OK] for 2 seconds to confirm." appears on the
LCD. Press and hold the [OK] key for 2 seconds or longer to delete the user setting
information and return the machine to the ready state.

Brother DCP-L5600DN Specifications

General

Type	all in one
Color	black/gray, multi
Touch Screen	yes
Display Size	3.7 inches
Tray Capacity	50
Output Tray Capacity	150 sheets
Automatic Document Feeder Capacity	70 sheets
Paper Size	ansi a, legal, executive, a4, a5, a6, folio
Paper Handling	letter, legal, executive, a4, a5, a6, envelopes, custom sizes (3.0-8.5" (w), 5.0-14" (l))
Paper Weight	60 grams per square meter
Printing Method	monochromatic
Color Print Speed	0 pages per minute
Mono Print Speed	42 pages per minute
First Page Print Time	7 seconds
Print Resolution Mono	up to 1200 x 1200
Two-Sided Printing	yes
Maximum Number of Pages Per Month	up to 50, 000
Reduction and Enlargement	no
Photo Printing	no
Scanner Type	flatbed
Scan Resolution	up to 1200 x 1200
Duplex Scan	yes
Max Copies	99
Copier Resolution Mono	up to 1200 x 600
Fax Function	no
Cartridges	brother tn820, brother tn850
Number Of Cartridges	1
Internal Memory	yes
Memory Card	no
Network	wired
Connectivity	usb 2.0, ethernet
Mobile Devices Connection	no

Weight and Dimensions

Depth	16.8 inches
Height	16.8 inches
Width	19.5 inches
Net Weight	37.7 pounds
